A certificate wants a SAN
Following my recent blog about creating you own CA you will find out, like I did, that the certs are quite wanting.
The Subject Alternate Name (SAN)
Even after importing the ca-chain.cert.pem
into your keyring / keystore Chrome will barf at the certificate, complaining about a missing SAN.
The idea of a SAN is to allow additional name variations to be recognised for one given certificate, reducing the effort for multi-purpose servers. E.g.: myawesomesite.com
, www.myawesomesite.com
, myawesomesite.io
, www.myawesomesite.com
, crazydata.com
I tried really hard, but at the time of writing, it seems the only way to create SAN for your certs is to provide a configuration file. I didn't find a command line option (short of various attempts on redirection and pipeing).
The hack I came up with:
Edit the intermediate\openssl.cnf
and add to the [ server_cert ]
section one line: subjectAltName = @alt_names
. The @
sign tells OpenSSL to look for a section with that name and expand its content as the parameter.
Using the following shell script generates a certificate that works for:
- www.domain (e.g.
www.awesome.io
) - domain (e.g.
awesome.io
) - domain.local (e.g.
awesome.io.local
)
The last one is helpful when you want to try SSL on localhost and amend your hosts
file to contain awesome.io.local
#!/bin/bash # Create new server certificates with the KEEP intermediate CA if [ -z "$1" ] then echo "Usage: ./makecert.sh domain_name (without www) e.g. ./makecert.sh funsite.com" exit 1 fi export SSL_DOMAIN_NAME=$1 export CONFNAME=intermediate/$1.cnf cat intermediate/openssl.cnf > $CONFNAME echo [alt_names] >> $CONFNAME echo DNS.0 = $SSL_DOMAIN_NAME >> $CONFNAME echo DNS.1 = www.$SSL_DOMAIN_NAME >> $CONFNAME echo DNS.2 = $SSL_DOMAIN_NAME.local >> $CONFNAME openssl ecparam -genkey -name prime256v1 -outform PEM -out intermediate/private/$SSL_DOMAIN_NAME.key.pem chmod 400 intermediate/private/$SSL_DOMAIN_NAME.key.pem openssl req -config $CONFNAME -key intermediate/private/$SSL_DOMAIN_NAME.key.pem -new -sha256 -out intermediate/csr/$SSL_DOMAIN_NAME.csr.pem openssl ca -config $CONFNAME -extensions server_cert -days 375 -notext -md sha256 -in intermediate/csr/$SSL_DOMAIN_NAME.csr.pem -out intermediate/certs/$SSL_DOMAIN_NAME.cert.pem chmod 444 intermediate/certs/$SSL_DOMAIN_NAME.cert.pem openssl pkcs12 -export -in intermediate/certs/$SSL_DOMAIN_NAME.cert.pem -inkey intermediate/private/$SSL_DOMAIN_NAME.key.pem -out intermediate/private/$SSL_DOMAIN_NAME.pfx -certfile intermediate/certs/ca-chain.cert.pem rm $CONFNAME
This will settle the Subject Alternate Name challenge. There are a more challenges to be had. Depending on what application you use, you need to import your intermediate keychain ca-chain.cert.pem
in multiple places in different formats (Remember, I urged you not to do that in production!).
On Mac and Linux you have a keychain, but NodeJS and Java don't recognize them. Edge (and its older sibling) have their own key store, as has Firefox. Python, depending on version and library, has its own ideas about keys too. So manual management is a PITA.
As usual YMMV
