The lowdown on Notes application web and mobile enablement


There are millions (if not billions) of lines of code written for the Notes client in small, large, simple, complex, epidermal and business critical applications. With the rise of browsers, tablets and mobile devices there is a need to web and mobile enable these applications, not at least since IBM won't let the C code of the Notes client run on iOS (which it could).
Whether we like it or not, that body of code can be considered technical debt.
  The strategy I see is mostly the same: classify applications by size, business criticality and perceived complexity. Then retire as much as possible and start a pilot for one (either insignificant or overly complex - mostly both) application using XPages. From there it goes nowhere.
Guess what. There's a better way.
Keep the part where you decide if an application can be retired. If you need to retain read access you could check out LDC Via, who remove the need to maintain a Domino infrastructure for those applications.
Then go and collect evidence (I know evidence based management isn't in fashion right now). There are elements in Notes that translate easily into web or mobile, parts that are hard and some stuff browsers can't do.
Collect how much you use of those, it makes decisions easier.

Design element and difficulty

  • View navigation:
    generally easy, its just data and Domino makes an excellent server for JSON data (I would render my own style, not the ?ReadViewEntries&Outputformat=JSON, but that's another story)
  • Categorised views:
    medium. The twisties we got so used to in Notes are not a native construct on the web (show me one that was web native). But with a little effort you can devise interaction patterns, go peek here.
  • View actions:
    HARD. They can be anything. Worst when code for front-end and back-end classes get mixed
  • Forms (read mode):
    Easy to medium. You could simply open a form using a browser and see something - or craft some XPage to show
  • Forms (edit mode):
    medium to hard (see below): You need to get your validation right and all the nice Hide-when conditions
  • RichText:
    HARD to impossible. RichText != HTML (and that's not even !==). For rendering you want to have Ben's enhancements as a start. RichText can contain attachments, wild formatting, OLE objects, Sections, Hidden stuff, tabbed or timed tables etc. All that doesn't really translate to HTML. To really know how RichText was used in your application and organisation you need to scan the actual data and analyse how RichText was used in each application
  • Code in forms:
    HARD. There is no LotusScript running in your browser, so you need to rewrite that logic. So better to know how many functions and lines of code you are looking at. Do your CoCoMo analysis. Code in fields (on enter/exit) needs to be re-though (nice word for retired)
  • Attachments:
    TEDIOUS. HTML doesn't know attachments, so you have to bridge between user expectations: can put an attachment anywhere in the text and the storage reality of HTML: simulate this by placing an image and a link. You might consider adding webDAV for a round trip editing experience
  • Reader & Author fields:
    Easy. Works
  • Encryption and Signature:
    (popular in approval applications) wait for Domino 9.0.2 - it supposedly will work there
  • Business Logic in hide-when formula:
    hard to find in Domino designer, DXL to the rescue
This list is probably not complete, but you get the gist

The approach

I would advocate (after the retirement of old applications):
  • Look at the whole application portfolio, not just one pilot. The best analogy: remember how long it took to drive your first 100m in a car (and I'm not talking about the 18 years wait to come of age). You had to take driving lessons (at least in civilized countries you have to), learn for the test, get a car (bargin with a parent?). So it took you around 20-40h, lets say: 20h. So you conclude to get to the supermarket, 3 km away it will take you 600h - so driving is out, you rather walk. Same applied to the "pilot". The first application is the hardest, so your experience wih it will screw the estimations.
    Furhermore looking at all applications gives you new synery potential and efficiency of scale
  • Create one module that handles view navigation for all applications (that probably would be a OSGi plug-in)
    When initially opening a document, it would point to a notes:// URL (you could have a little icon indicating that). Within a few weeks you have a working application giving some access to your Notes data (I would use JSON, AngularJS and Ionic for that app)
  • Next generate the forms using angular-formly or some {{mustache}} templates, so you have read-only access (DXL and XSLT skills come in handy)
  • Add a "request" functionality that lists the functions (Action buttons) an application once had, let users propose "I want this", so you get some priorities sorted out
  • Transit to contemporary development with a Domino backend
  • Do not fall into the trap: must look and work like a Notes client (we had that with the Java applets in R5 - last century). If someone is happy with the look of the Notes client - give them the IBM Client access plugin (PC only)

Why no magic button?

You could ask: why doesn't IBM provide this as an automatic module? After all they wrote LotusScript, the formula language and the Notes client. The short answer: IBM tried, we even had a prototype of LotusScript running on the JVM. The Notes client is such an incredible forgiving environment, any quality and mix of code "simply runs"™. I've seen code happily running (yes I'm talking about you 8000-lines-function) that was a melange of unspeakables.
Browsers on the other hand are fragile and unforgiving (not talking about quirks mode here). Any attempt to automate that never reached the stage of "point-and-shoot" - so it will not become an offering.

Why not just default and rewrite?

Good idea. Until you look closer. Domino's declarative security (ACL, Reader and Author fields anyone) is hard to replicate. The schema free Domino NoSQL store does neither map to Sharepoint nor an RDBMS (CouchDB could work), so you suddenly deal with data migration - a nightmare that can eat 80% of your total project cost. Lastly, the incremental approach outlined here allows to continue to use the applications (and eventually enhance them along the way), so disruption is minimised. Also the working Notes client provides a fallback for missing or malfunctioning features, this substantially lowers application risks.

Business partners to the rescue

You are not alone on this journey. IBM business partners and IBM Software Services for Collaboration are here to help. If you like the approach "I see Notes as one huge pool", you might want to talk to Redpill, they perfected this approach.

As usual YMMV.

Posted by on 03 November 2015 | Comments (5) | categories: IBM Notes

Comments

  1. posted by Stephan Wissel on Wednesday 04 November 2015 AD:
    @Mat: I mentioned you in the article already Emoticon wink.gif
  2. posted by Ray on Wednesday 04 November 2015 AD:
    Hi Stephan, good article. Nice to see you still active in this area. LDC Via seems like a good compromise and steers you away from the 80% money pit!
  3. posted by Matt White on Wednesday 04 November 2015 AD:
    Another alternative is our offering at LDC Via which migrates NSF data to mongodb and then adds a security layer that matches readers and authors fields using our API. During the migration we transfer rich text, file attachments and response heirarchies.

    { Link }
  4. posted by Richard Moy on Thursday 05 November 2015 AD:
    The other alternative is to treat your Domino server only as a database server. Create restful services to the data and use a MVC framework for the front end. You can then gradually transition to other technologies or stay with Domino or a combination. The front end is now data source agnostic and can be more easily maintained.
  5. posted by Ben Poole on Thursday 05 November 2015 AD:
    I suspect Matt was getting at the fact that with LDC Via we’re not just read-only Emoticon wink.gif
