Protecting sensitive information in Notes documents

Even in the most social businesses there is information that is available only on a "need to know" basis. Sometimes it is only a small subset of the fields in a document. In a Notes client, as long as I can see a document, I can see all the item values in it (using the document properties box), even if the field is hidden in the current form. So what are my options to protect a few sensitive fields?:

Encrypt the fields with an encryption key that only the authorised user have. Problem here: you need to manage these keys and need a different set for each use case - messy. Also you can't show any of these fields in a view
Hide the database design when applying the template. Looks good on the first view, but a semi skilled user can easily bypass that (e.g. copy & paste into an empty database, create a private view, use a @Prompt smart icon, use the free Document viewer or NotesPeek) - security by obscurity never works
Store the sensitive data in a second document that is protected by reader names that are different (more restrictive) than the main document. This approach also keeps (given you have security set) curious admins out, a capability RDBMS is lacking
Change the process and remove the need for the fine grained access control

Let's have a closer look at option 3. Notes allows to pull in values from a different document using @GetDocField. So once we have the secret document, we can pull in these values. If a user can't see that document no value is retrieved. The formula for such a computed for display field would look like this:

@If (RiskAssessmentID= "";@Return ( "n/a" ); "" );
tmp := @GetDocField (RiskAssessmentID; "RiskAssessment" );
@If ( @IsError (tmp ); "nothing to retrieve";tmp )

To create such a "secondary document" a few lines of LotusScript in a button make it a seamless experience:

Sub Click (Source As Button )
Dim doc As NotesDocument
Dim riskDoc As NotesDocument
Dim uiDoc As NotesUIDocument
Dim db As NotesDatabase

Dim w As New NotesUIWorkspace
Set uidoc = w. CurrentDocument
Set doc = uidoc. Document
If doc. IsNewNote Then
Call doc. Save ( True, True )
End If
Set db = doc. ParentDatabase
If doc. RiskAssessmentID ( 0 ) = "" Then
Set riskDoc = db. CreateDocument
Call riskDoc. ReplaceItemValue ( "Form", "RAF" )
Else
Set riskDoc = db. GetDocumentByUNID (doc. RiskAssessmentID ( 0 ) )
If riskDoc Is Nothing Then
Set riskDoc = db. CreateDocument
Call riskDoc. ReplaceItemValue ( "Form", "RAF" )
End If
End If

Call riskDoc. MakeResponse (doc )

If w. DialogBox ( "RAF", True, True, False, False, False, False, "Please provide your Risk Assessment",riskDoc, True ) Then
Call riskDoc. Save ( True, True )
Call doc. ReplaceItemValue ( "RiskAssessmentID",riskDoc. UniversalID )
Call doc. Save ( True, True )
End If

Call uidoc. Refresh

End Sub

To keep the 2 documents in sync we add some code into the PostSave event of the main form:

Sub Postsave (Source As Notesuidocument )
Dim doc As NotesDocument
Dim riskDoc As NotesDocument
Dim db As NotesDatabase

Set doc = source. Document

If doc. RiskAssessmentID ( 0 ) = "" Then
Return
End If

Set db = doc. ParentDatabase
Set riskDoc = db. GetDocumentByUNID (doc. RiskAssessmentID ( 0 ) )

Call riskDoc. ReplaceItemValue ( "Subject",doc. subject )
'Repeat with other fields needed in views, for workflow and access control

Call riskDoc. Save ( True, True )

End Sub

We are almost done. The response documents need some handling when we try to open them.Ideally instead of opening the response we would open the main document. The code in the view's QueryOpenDocument event takes care of that:

Sub Queryopendocument (Source As Notesuiview, Continue As Variant )
Dim id As String
Dim Doc As NotesDocument
Dim parentDoc As NotesDocument
Dim db As NotesDatabase
Dim ws As New NotesUIWorkspace
Dim s As New NotesSession

id = Source. CaretNoteID

If id = "" Then
Continue = True
Exit Sub
End If

Set db = s. CurrentDatabase
Set doc = db. GetDocumentByID (id )

If Not doc. IsResponse Then
continue = True
Exit Sub
End If

continue = False

Set parentDoc = db. GetDocumentByUNID (doc. ParentDocumentUNID )
Call ws. EditDocument ( False,parentDoc )

End Sub

You also need to take care of deletion of documents. Only a user who can see both should be allowed to delete them (or you "flag" them for deletion and let a background agent do the actual deletion). I leave this to you as an exercise. In a real world application you would of course pack all these code into LotusScript objects that live in a ScriptLibrary.
XPages simply woud use 2 data sources and save us the trouble of building a dialog box.
As usual YMMV

Posted by Stephan H Wissel on 04 November 2011 | Comments (1) | categories: Show-N-Tell Thursday

posted by Karsten Lehmann on Saturday 05 November 2011 AD:
And you should keep in mind that protecting documents with reader fields do not hide them in any case. With designer access on the database you can create a view, activate the option to show empty categories and use category formulas to get information about the document content. You can even use @DocFields to get a list of item names to find out what to look for.
IMHO this does not work with personal views, because they get generated and stored on the Notes Client. But "normal views" get created by the indexer which has access to all documents.
Removing the summary flag from secret items could help. Then they can't show up in views.
